*IMPORTANT*: When the MoCA LED is GREEN on both adapters, your adapters are working.Ĭonnect a networking device using a LAN cable to either of the network ports and test connection. Connect a coax cable from the splitter to the MoCA port of the Network Adapter.Locate the coax wall outlet and connect a coax cable from the wall outlet to a MoCA splitter.POE Filter: A POE filter may be used at the point of entry if needed. If you have a TV or set-top box near your modem, connect a coax cable from the splitter to the TV or set-top box. Connect one coax cable from the splitter to the MoCA port of the Network Adapter and another coax cable from the same splitter to the coax port of the cable modem.

Note: make sure the splitter is a MoCA splitter that supports frequencies up to 1675MHz.

Connect a MoCA splitter to the coax cable coming from the coax outlet on the wall.

Connect one ethernet cable from the Cable Modem to the TL-MC84 Network Adapter.

(MoCA Adapter Connection to a Cable Modem) It is important that you do not form a loop in your connection. There are two 1G ports that can be used as a HUB to connect to more than one networking device.

Connect a networking device using a LAN cable to either of the network ports and test the connection.

*IMPORTANT*: When the MoCA LED is GREEN on both adapters, your adapters are working

Locate the coax wall outlet and connect a coax cable from the wall outlet to the MoCA port of the Network Adapter.

Unbox your second MoCA 2.5 Network Adapter.

(Splitter Connection: Connect a splitter to the coax cable coming from the coax outlet on the wall and then connect a coax cable from the splitter to the MoCA port of the Network Adapter) If you have a splitter, make sure the splitter is a MoCA splitter that supports frequencies up to 1675MHz.

Connect a coax cable from the MoCA port on the Network Adapter to the coax wall outlet.

Connect one ethernet cable from the router to the TL-MC84 Network Adapter.SCAN THE QR CODE NOW TO DOWNLOAD Setup Instructions: (MoCA Adapter Connection to a Router Setup) With simple powerful guides and illustrations we help through setup and support of your MoCA® adapter.Įasily downloaded to a phone or any other device supporting PWA’s.
